5 in 1 DELTA Shop - $300 (WRJ, VT)
QR Code Link to This Post
This Delta-Shop / Homecraft has the important things - the Table-saw and the 4" Jointer.
It includes the sander, but it does not appear to be complete.
It does include the jigsaw attachment !
And I added R/D Castor wheels from another D/R machine - They are great !!!!
Sorry no pic. yet - It's in good condition, and the TS and the Jointer works great !
The 1st pic. is about how the machine looks now.
I have run out of room in my small shop, so it has to go … ;(
___________________________________________________________________
Delta Homecraft Bench Model 8" Tilting Arbor Saw Model No. 34-500 Specifications
Overall dimensions - 17 1/2" high by 37 1/2" wide by 22" deep
Diameter of Arbor - 5/8"
Diameter of Saw - 8"
Maximum Thickness of Cut - 2 1/4"
Maximum Thickness of Cut at 45 Degrees - 1-9/16"
Maximum Width of Dado Cut - 13/16"
Blade Tilt - 45 Degrees
Table in front of blade on capacity cut - 11-5/8"
Maximum rip to right of blade - 24"
Table working height on steel stand - 34 1/2"
Table Size - 22" deep by 15" wide
Table Size with extensions - 22" deep by 25" wide
Fence - 24 7/8" long by 2" high
